| Model No.: | CSCFTT005 |
| Fuel Tank Volume: | 5,000 Liters |
| Dimensions(LxWxH): | 9,950×2,490×3,350mm |
| Chassis Brand: | Dongfeng |
| Drive Type: | 6×4 |
| Loading Weight: | 14,200kg |
| Wheelbase: | 4,350+1,300mm |
| Engine Power: | 180HP |
| Emission Standard: | EURO V |
| Max. Speed: | 90 km/h |
| Tank Body Shape: | Square Round Cylinder |
| Tank Body Material: | Carbon steel/Stainless Steel/Aluminum Alloy |
Description
BRIEF
The 10-wheeler fuel tank truck is a robust and efficient solution for fuel transportation. Manufactured by CSCTRUCK China Tank Truck, this vehicle is designed to meet the demands of modern fuel delivery while adhering to stringent environmental and safety standards.
The fuel tank truck, equipped with a 5,000-liter fuel tank, ensures substantial fuel-carrying capacity, making it ideal for commercial and industrial applications. The tank is built for durability and safety, incorporating advanced anti-corrosion materials and secure compartmentalization for safe fuel handling.
The truck is built on a Dongfeng chassis, which is known for its reliability and performance in heavy-duty operations. Its 6×4 drive type offers excellent traction and stability, ensuring smooth operation even on challenging terrain.
Powered by a 180HP engine compliant with the EURO V emission standard, the truck combines power and environmental responsibility. The engine delivers efficient fuel consumption and reduced emissions, making it a sustainable choice for businesses. Its maximum driving speed of 90 km/h ensures timely deliveries without compromising safety.
The 10-wheeler configuration enhances load distribution and stability, making the vehicle well-suited for heavy payloads. Designed with operator comfort and safety in mind, the truck’s cabin includes ergonomic controls and modern features for ease of use.
Overall, the 10-wheeler fuel tank truck is a versatile, high-performance vehicle designed for reliable and eco-friendly fuel transport.
FEATURES
1. Large Fuel Tank Capacity:
  – The truck is equipped with a 5,000-liter fuel tank, ideal for fuel transportation and distribution.
2. Robust Chassis:
  – Built on a Dongfeng chassis, known for durability and reliability in various demanding conditions.
3. Efficient Drivetrain:
  – The truck features a 6×4 drive type, providing enhanced traction and stability for different terrains.
4. Powerful and Eco-Friendly Engine:
  – Powered by a 180HP engine, compliant with the EURO V emission standard, ensuring high performance and reduced environmental impact.
5. Good Speed Capability:
  – The truck has a maximum driving speed of 90 km/h, balancing speed and safety for fuel transport operations.
SPECIFICATION
Chassis |
|
| Driving model | DONGFENG 6×4 |
| Cabin | LHD, with Air Conditioner |
| Overall dimensions(LxWxH) | 9,950*2,490*3,350 (mm) |
| Curb Weight | 10,505kg |
| Loading Weight | 14,200kg |
| Wheelbase | 4,350+1,300(mm) |
| Engine | Diesel, 6-cylinder in-line with water cooling |
| 180hp, Euro III, IV, V | |
| Gearbox | 10 forwards and 2 reverse |
| Axle Load(kg) | 7,000/17,900 |
| Tire | 10.00R20Â tubeless tire, 11pcs |
| Max speed | 90 km/h |
| Steering Gear | Power steering, hydraulic steering with power assistance. |
Tank Body |
|
| Shape | Square/Round/Cylinder |
| Tanker Body Material | Carbon steel/Stainless Steel/Aluminum Alloy |
| Tank thickness | 5mm |
| Total Volume(L) | 5,000 |
| Compartment | Optional |
| Transport oil type | Diesel/Petrol |
| Manhole cover | Manhole cover with breath valves, 500mm |
| Bottom Valve | 1Â set |
| Discharging valve | 1Â set |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, and 2 coats of final paint. |
| Accessories | One standard toolbox. |
| Remarks | Oil pump: Self-priming pump, gear pump optional. Oil meter: Single, double, Fiscal processor optional. Fuel Dispenser optional. Equipped with a ladder on the tank. |
Additional information
| Tank Mounted on Chassis Brand |
|---|
