Model No.: | 10 Wheelers 20000 Liters Fuel Tank Truck |
Fuel Tank Volume: | 20,000 Liters |
Overall Dimensions(LxWxH): | 8,700×2,500×3,450mm |
Chassis Brand: | Sinotruk HOWO |
Wheelbase: | 3,625+1,350mm |
Drive Type: | 6×4 |
Engine Model: | WD615.47 |
Engine Power: | 371HP |
Emission Standard: | Euro 2 |
Rated Loading Weight(kg): | 20,000 |
Fuel Tank Material: | 4mm or 6mm high-quality carbon steel |
Categories: Carbon Steel Tank Truck, Fuel Tank Truck
Description
BRIEF
The 10 wheelers 20000 liters fuel tank truck manufactured by CSCTRUCK China Tank Truck embodies the pinnacle of reliability and efficiency in the transportation of liquid fuel. With a capacious 20,000 liters fuel tank volume, this vehicle is a testament to cutting-edge engineering and superior craftsmanship.
Built on the sturdy Sinotruk HOWO chassis and boasting a formidable 6×4 drive type, this fuel tank truck ensures optimal performance even in the most demanding terrains and weather conditions. The WD615.47 engine model, generating a robust 371HP engine power, empowers the vehicle with ample strength to easily tackle long hauls.
Committed to environmental sustainability, the fuel tank truck adheres to Euro 2 emission standards, minimizing its carbon footprint while maximizing fuel efficiency. Its impressive 20,000kg payload capacity allows for significant quantities of fuel to be transported in a single trip, enhancing operational efficiency and cost-effectiveness.
Durability is paramount, and the fuel tank is constructed from either 4mm or 6mm high-quality carbon steel, ensuring resilience against corrosion and structural integrity over extended periods of use. Whether traversing rugged terrains or navigating urban landscapes, this fuel tank truck exemplifies reliability, efficiency, and durability, making it the preferred choice for transportation companies and fuel distributors.
FEATURES
1. Tank Capacity: The truck boasts a substantial fuel tank capacity of 20,000 liters, ensuring it can carry a significant amount of fuel in a single trip.
2. Chassis: It is built on a sturdy Sinotruk HOWO chassis, renowned for its durability and reliability in heavy-duty applications.
3. Drive Type: With a 6×4 drive type, this fuel tank truck ensures superior traction and stability even on challenging terrains, making it suitable for various transportation tasks.
4. Engine Model: Powered by the WD615.47 engine model, known for its robust performance and fuel efficiency, providing the necessary power to carry heavy loads over long distances.
5. Engine Power: The truck delivers impressive power with a 371HP engine, enabling it to tackle demanding transport routes and gradients with ease.
6. Emission Standard: Compliant with Euro 2 emission standards, the truck minimizes its environmental impact while adhering to regulatory requirements.
7. Payload Capacity: With a payload capacity of 20,000kg, this tank truck is capable of transporting substantial loads of fuel efficiently and cost-effectively.
8. Tank Material: The fuel tanker is constructed using high-quality carbon steel, with options for either 4mm or 6mm thickness, ensuring durability and resistance to corrosion for long-term use.
9. Safety Features: Equipped with safety features such as an anti-lock braking system (ABS) and advanced suspension systems, ensuring safe handling and stability during transportation.
10. Customization Options: CSCTRUCK China Tank Truck offers customization options to meet specific customer requirements, including variations in tank capacity, chassis configuration, and additional features tailored to different applications.
SPECIFICATION
10 Wheelers 20000 Liters Fuel Tank Truck |
||
Chassis Model | ZZ1257N4341W (Left/ Right Hand Driving Type Optional) | |
Engine | Model: WD615.47 Euro 2, 371HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L |
|
Clutch | Single-plate dry diaphragm spring clutch, diameter430mm, hydraulically operating with air assistance | |
Gearbox | SINOTRUK BRAND, manual operation, HW19710, 10 forward and 2 reverse | |
Front Axles | HF9, 9,000kg with drum brake system(or HF7,7000kg with drum brake system) | |
Rear Axles | HC16, 2X16,000kg, double stage reduction (central+ hub), cast axle housing, ratio: 4.42, 4.8, 5.73, OR ST16, 2X13,000kg, double stage reduction (central+ hub), cast axle housing, ratio: 3.93, 4.42, 4.8, OR MCY13Q, 2X13,000kg, central single stage reduction, ratio: 3.08, 3.36, 3.7, 4.11, 4.63 |
|
Suspension | Front suspension: 10 pcs (or 3 pcs) leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension: 12 pcs (or 5pcs or 15pcs) leaf springs with bogie spring and stabilizer |
|
Rear suspension: 12 pcs leaf springs with bogie spring and stabilizer | ||
Steering System | Brand power steering, model 8118, hydraulic steering with power assistance | |
Braking System | Front drum rear drum brake, 4-circuit protection valve Service brake: Dual circuit compressed air brake Parking Brake(emergency brake): Spring energy, compressed air operating on rear wheels Auxiliary brake (optional): Engine exhaust brake(EVB), antilock brake system (ABS), automatic brake gap adjustment arms |
|
Tires | 12.00R20 (12.00-20,315/80R22.5, 295/80R22.5. 12R22.5, 12.00R24 optional), with 1 spare tyre | |
Fuel Tank Volume(L) | 20,000L | |
Dead Weight(kg) | 13,500 | |
Gross Vehicle Weight(kg) | 20,000 | |
Rated Combination Weight(kg) | 33,500 | |
Rated Loading Weight(kg) | 20,000 | |
Overall Dimension(LxWxH)(mm) | 8,700×2,500×3,450 | |
Wheelbase(mm) | 3,625+1,350 | |
Min. Ground Clearance(mm) | 314 | |
Approach/Depart Angle(°) | 16/(26/35) | |
Gradeability(%) | ≥50 | |
Min. Turning Diameter(m) | 15 | |
Effective Mixing Volume(m3) | 20+5% | |
Remark (Engine Power Option) | 371HP | |
Cargo Volume | 20M3 | |
Mixer Body |
|
