Model No.: | 10 Wheelers 20 CBM Crude Oil Tank Truck |
Crude oil tank volume: | 20 CBM |
Overall dimensions(LxWxH): | 9,600×2,500×3,300mm |
Chassis Brand: | Dongfeng |
Drive Type: | 6×4 |
Wheelbase: | 4,350+1,300mm |
Engine Model: | C260 33 |
Engine Power: | 260HP |
Emission Standard: | Euro 2 |
Crude Oil Tank Material: | Carbon steel |
Categories: Carbon Steel Tank Truck, Crude Oil Tank Truck
Description
BRIEF
The 10-wheelers 20 CBM crude oil tank truck produced by CSCTRUCK China Tank Truck is a robust and efficient vehicle designed for the safe and effective transportation of crude oil. This tank truck is built on a reliable Dongfeng chassis, which is known for its durability and performance in various driving conditions.
The crude oil tank truck features a 6×4 drive type, providing excellent traction and stability, which is crucial for transporting heavy loads over long distances. Powered by a C260 33 engine model, the vehicle boasts a substantial 260 horsepower, ensuring it can handle demanding routes with ease. The engine adheres to the Euro 2 emission standard, reflecting a balance between performance and environmental considerations, although newer standards might offer better emission controls.
The tank itself is made of high-quality carbon steel, chosen for its strength and resistance to the corrosive nature of crude oil. With a capacity of 20 cubic meters (CBM), the tank truck is well-suited for significant quantities of crude oil, making it ideal for use in oil fields, refineries, and distribution networks.
CSCTRUCK China Tank Truck has equipped this vehicle with features aimed at enhancing operational efficiency and safety. The robust construction and engineering precision ensures that the truck can perform reliably in diverse and often challenging terrains. Overall, the 10-wheelers 20 CBM crude oil tank truck by CSCTRUCK China Tank Truck offers a compelling combination of power, capacity, and durability, making it a valuable asset for companies involved in the oil transportation sector.
FEATURES
1. Chassis and Drive Type:
  – Dongfeng Chassis: This tank truck is built on a robust Dongfeng chassis, known for its durability and reliability.
  – 6×4 Drive Type: The 6×4 drive configuration means it has 6 wheels, with power delivered to four of them, offering enhanced traction and stability.
2. Engine Specifications:
  – Engine Model: The truck is powered by the C260 33 engine model, a specific variant providing balanced performance and fuel efficiency.
  – Engine Power: With 260 horsepower(HP), this engine offers sufficient power for transporting heavy loads, including up to 20 cubic meters of crude oil.
3. Emission Standard:
  – Euro 2 Emission Standard: The engine complies with the Euro 2 emission standard, reflecting moderate emission control technology suitable for certain regions with less stringent environmental regulations.
4. Tank Material and Capacity:
  – Carbon Steel Crude Oil Tank: The tank is constructed from carbon steel, providing strength and resistance to corrosion, essential for safely transporting crude oil.
  – 20 Cubic Meter Capacity: The tank has a substantial capacity of 20 cubic meters, making it suitable for transporting large volumes of crude oil efficiently.
5. Overall Configuration:
  – 10-Wheeler Configuration: The truck features a 10-wheeler design, enhancing load distribution and vehicle stability, especially important for heavy cargo like crude oil.
SPECIFICATION
Vehicle Description |
||
Overall dimensions(LxWxH) | 9,600×2,500×3,300mm | |
GVW | 25,000kg | |
Curb weight | 10,805kg | |
Chassis brand | Designated vehicles | |
Traction type | 6×4, left/right hand drive | |
Chassis Description |
||
Chassis model | DFL1250A8 | |
Cab | Sleeper cab, forward control type, low roof, new face, all welded, steel cab of tilt type, mechanical cab tilting, rear mechanical cab | |
Wheelbase | 4,350+1,300mm | |
Tire specification | 11.00-20 | |
Tire quantity | 10+1units | |
Engine | Engine model | C260 33 |
Emission level | Euro 2 | |
Displacement/output | 8,300ml/191kW | |
Horsepower | 260HP | |
Brake system | Full air brake system split pneumatic circuit: parking spring brake acting on rear aes, exhaust brake. | |
Axle | Front | 7T- Elliot type, I beam section |
Rear | 10T*2-Single Reduction | |
Gearbox | Type | RT-11509C DD |
Number of gears | 9 forward gears&1reverse, synchronized | |
Suspension | Front | 8 Leaf spring with shock absorber |
Rear | 9 Leaf spring | |
Fuel tanker | Type | Steel fuel tank with lockable cap |
Capacity | 350L | |
Up-part Description |
||
Tanker | Capacity | 20 CBM |
Material | Carbon steel | |
Thickness | 5mm | |
Standard configuration | Equipped with 4 set manhole. Equipped with a double discharge valve and valve box. Equipped with surge baffles, ladder, roof coaming, skid-resistant walkway, and toolbox. Equipped with electrostatic conducting tape and double-fire extinguishers. |
