Model No.: | 10 Wheelers 20 CBM Corrosive Tank Truck |
Overall Dimensions(LxWxH): | 9,500×2,500×3,210mm |
Drive Type: | 6×4 |
Wheelbase: | 4,300+1,350mm |
Payload: | 25,000Kg |
Max. driving speed(km/h): | 90 |
Engine Brand: | SINOTRUK |
Engine Model: | WD615.69 |
Horse Power(HP): | 336 HP |
Emission standard: | Euro 2 |
Tank Size: | 20,000liters |
Tank Material: | Q235 Carbon Steel. End plate thickness: 5mm, tanker body thickness: 5mm |
Categories: Carbon Steel Tank Truck, Corrosive Tank Truck
Description
BRIEF
The 10 wheeler 20 CBM corrosive tank truck, manufactured by CSCTRUCK China Tank Truck, boasts formidable specifications for heavy-duty transport. Featuring a 6×4 drive type, it can navigate various terrains effortlessly while carrying a substantial payload of 25,000 kilograms. With a maximum driving speed of 90 km/h, it ensures swift and efficient transportation. Equipped with a WD615.69 engine model delivering 336 horsepower, it promises robust performance and reliability on the road.
Its 20,000-liter tank capacity is constructed from Q235 Carbon Steel, ensuring durability and resistance against corrosive materials. This 10 wheeler 20 CBM corrosive tank truck is engineered to safely transport corrosive substances, meeting stringent industrial standards. Whether for industrial applications or specialized transport needs, this 10 wheeler 20 CBM corrosive tank truck offers a combination of power, capacity, and safety features essential for demanding tasks.
FEATURES
1. High Capacity Tank: The 10-wheeler 20 CBM corrosive tank truck produced by CSCTRUCK China Tank Truck boasts a substantial 20,000 liters tank capacity, providing ample space for transporting corrosive materials efficiently and effectively.
2. Robust Construction: Constructed from Q235 Carbon Steel, the tank of this truck is built to withstand the corrosive nature of the materials it carries, ensuring durability and longevity even under challenging conditions.
3. Powerful Engine: Equipped with a WD615.69 engine model, delivering 336 HP engine power, this tank truck offers robust performance capabilities, enabling it to handle demanding transport tasks with ease.
4. Enhanced Payload Capacity: With a payload capacity of 25,000 kg, this tank truck is optimized for transporting substantial loads, making it ideal for industrial applications where large volumes of corrosive materials need to be safely and efficiently transported.
5. Versatile Drive Type and Speed: Featuring a 6×4 drive type and a maximum driving speed of 90 km/h, this tank truck offers versatility in navigating various terrains and road conditions while maintaining an efficient pace, enhancing productivity and operational flexibility.
SPECIFICATION
 SINOTRUK HOWO 6X4 Fuel truck-20,000L |
||
Driving type | 6×4, LHD | |
Cabin | HW76 cab, with one bed and air conditioner, 70°hydraulically tillable to the front. | |
Vehicle Main Dimensions | Overall dimensions(LxWxH)mm | 9,500×2,500×3,210 |
Wheelbase(mm) | 4,300+1,350 | |
Wheel track(front/rear)(mm) | 2,020/1,800 | |
Weight in KGS | Tare Weight | 13,500 |
Payload | 25,000 | |
Front axle loading capacity | 1×7,000 | |
Rear axle loading capacity | 2×16,000 | |
Max. driving speed(km/h) | 90 | |
Engine | Brand | SINOTRUK |
Model | WD615.69 | |
Type | 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charged | |
Inter-cooled | ||
Horse Power(HP) | 336HP | |
Emission standard | Euro 2 | |
Gearbox | HW15710, 10-speed forward and 2 reverse gear. | |
Clutch | Reinforced diaphragm clutch, diameter 430mm. | |
Steering | ZF8098, power steering, hydraulic steering with power assistance. | |
Oil tank | 400 liters | |
Tire | 12R22.5 tubeless tire 11 pcs including one spare tire. | |
Tank Size | 20,000liters | |
Tank Material | Q235 Carbon Steel. End plate thickness: 5mm, tanker body thickness: 5mm. |
